Branch outlets to MSS SP-97

Integrally reinforced olets for branch connections, forged in the same grades as our flanges.

Outlet types

Each outlet type, drawn so you can pick the right one.

Weldolet. Butt-weld branch, wall matched to the branch schedule

Sockolet. Socket-weld branch, Class 3000 and 6000

Threadolet. Threaded (NPT) branch, Class 3000 and 6000

Elbolet. Branch on the outside of an elbow

Latrolet. 45° lateral branch

Sweepolet. Contoured, low-stress branch for high-pressure lines

Nipolet. Integral nipple branch for vents and drains

Example: weldolet 12 x 2 inch, Sch 80 branch, ASTM A182 F316L.

Send sizes, grades and quantities. Our estimation team usually replies within one working day.

Butt-weld fitting grades
Material	Fitting specification	Notes
Carbon steel	ASTM A234 WPB, WPC	Seamless and welded	Quote
Low-temperature carbon steel	ASTM A420 WPL6, WPL3	Impact tested to -46°C (WPL6)	Quote
High-yield pipeline	MSS SP-75 WPHY 42 to 70	For API 5L line pipe	Quote
Chrome-moly	ASTM A234 WP5, WP9, WP11, WP22, WP91	Normalised and tempered	Quote
Austenitic stainless	ASTM A403 WP304/304L, WP316/316L, WP321, WP347, WP310S	Class S, W and WX	Quote
Super-austenitic	ASTM A403 WP904L, WPS31254 (guide)	Seamless and welded	Quote
Duplex and super duplex	ASTM A815 WPS31803, WPS32205, WPS32750, WPS32760 (guide)	Ferrite and A923 tests on request	Quote
Titanium	ASTM B363 WPT1, WPT2, WPT7, WPT12 (guide)	Grade 5 on enquiry	Quote
Nickel alloys	ASTM B366 WPNCMC, WPNICMC, WPHC276, WPNC, WP20CB (guide)	Seamless and welded	Quote
Copper-nickel	90/10 and 70/30 to EEMUA 146 or project spec (guide)	Seamless and welded	Quote

FAQ

Are olets made from forgings?

Yes. MSS SP-97 branch outlets are machined from forgings in the same grades as forged flanges and B16.11 fittings.

Request a quote

Send your BOQ, drawing or tender reference. You deal directly with the manufacturer.

Drawings and BOQ spreadsheets are easiest by email. Mention your project name.
